Smart Hardware Battery Pack

Smart Hardware Lithium Battery Packs

Gushine, with advanced control circuits, smart battery technology, and rugged structure, creates custom battery modules that meet the backup or standalone power needs in extreme environments. Key features include:

High energy density & low internal resistance for superior discharge performance.
Operates reliably from –40°C to 85°C in all climates.
Up to 10 years lifespan, 5000+ cycles for industrial & IoT devices.
Real-time EOL indicator for proactive IoT device battery monitoring
Low self-discharge for long term, stable operation.

The Gushine smart hardware & IoT battery pack features high capacity and a long lifespan, making it ideal for IoT applications. Our smart battery solutions integrate engineering design, rigorous testing, and proven manufacturing expertise to ensure reliable performance.

Custom Lithium Battery Pack

Industry Applications

Smart Fascia gun

Intelligent Floor Scrubber

Robot Vacuum Cleaner

Intelligent Portable Projector

Intelligent Bluetooth Speaker

Intelligent Security Monitoring

Smart Hardware & IoT Battery Solution

Battery Protection Board

Overcharge/overdischarge protection, overcurrent protection, short circuit protection, and temperature monitoring.

High-strength Bracket

shockproof and drop-resistant

Cushion EVA

impact and vibration protection

Cylindrical Battery Module

18650 cells / 3S1P

Battery Heat Shrink Film

provides insulation protection

Featured Models

14.4V 2500mAh Massage gun lithium battery pack

Model: QR005B-RBA-4S1P
Rated Capacity: 2500mAh
Nominal Voltage: 14.4V
Dimensions: 164.3(L) x 44.4(W) x 26.85(T) mm
Features: Precise guage, type-C interface
Application: Massage guns

3.63V 4900mAh Security monitoring lithium battery pack

Model: RL003B-RBA-1S1P
Cell: 21700 / 4900mAh / 3.63V
Rated Capacity: 4900mAh
Nominal Voltage: 3.63V
Application: Security monitoring backup power

Smart Hardware & IoT Solution Overview

Featured Batteries

Items	Details
Battery Cell	18650, Lipo battery cells, Prismatic cells
Configuration	1S-6S
Capacity	1500mAh-10000mAh
Temperature	Charge: 0℃ to 45℃ Discharge: -20℃ to 60℃
Protection	Shock-resistant, waterproof, overcurrent, overvoltage, temperature protection, fire-retardant housing
Hardware & Software	MCU, gauge, temperature monitoring, real-time communication (I²C,SPI), protection circuit, fault diagnosis and protection

Premium cells

Battery packs using high quality cells from LG, Samsung, Panasonic and other top tier manufacturers, ensuring long-lasting performance and reliability.

Dust-proof and waterproof

IP67, IP 68 rated, ensuring safe operation in hazardous environment.

Real-time Communication

I²C communication function, ensuring seamless and reliable data transmission.

Company News

Inquiry Form

Choose Gushine for professional, reliable, and high-quality custom lithium battery solutions. Contact us today to get started on your custom battery project!
