The battery supports CC/CV charging, with a standard charging current of 1250 mA and a maximum charging current of 1500 mA. The standard discharge current is 500 mA, while the maximum continuous discharge current reaches 4000 mA, providing stable power for robotic vacuum operation. It also supports discharge from −20°C to +60°C, making it suitable for cleaning tasks across a wide range of operating temperatures.

Product Specifications & Configuration
Battery Model: BL006B-RBA
Cell Type / Capacity: ICR18650/2600mAh
Battery Configuration: The finished battery pack consists of 3 cells in a 3S1P configuration and a protection control circuit (PCM).

Basic Performance

No.	Item		Parameter	Remarks
1	Capacity		Typ.2600mAh	0.2C Discharge
			Min.2500mAh
2	Nominal Voltage		10.8V
3	Charge Limit Voltage		12.6V
4	Maximum Charging Voltage		12.63V
5	Discharge Cut-off Voltage		8.25V
6	Charging Method		CC-CV
7	Charging Current		618 mA
			1235 mA
8	Discharge Current		1250mA
			1500 mA
9	Standard Discharge Current		1250 mA
10	Maximum Discharge Current		1500 mA
11	Operating Temperature	Charging	0°C~+10°C	Charging Current: 500 mA
			10°C~+20°C	Charging Current: 1250 mA
			20°C~+45°C	Charging Current: 1500 mA
		Discharging	-20°C~+60°C
12	Storage Temperature	Less than 1 Month	-20°C~+60°C	Capacity Recovery ≥ 80%
		Less than 3 Months	-20°C~+45°C
		Less than 1 Year	-20°C~+25°C
13	Relative Humidity		65±25%
14	Battery Internal Resistance		≤ 240mΩ	AC internal resistance measured at 1 kHz after standard charging.
15	Battery Weight		133g	About
16	Battery Dimensions	Length	Max134mm
		Width	Max38mm
		Thickness	Max20.5mm

Stable Runtime: Typ. 2600 mAh and Min. 2500 mAh capacity support continuous operation of robotic vacuum cleaners.

Efficient Charging & Discharging: Supports a maximum charging current of 1500 mA and a maximum discharge current of 4000 mA, balancing charging efficiency with operating power demands.

Wide-Temperature Operation: Supports discharge from −20°C to +60°C, improving battery adaptability across different operating temperatures.

Compact & Lightweight: The battery pack weighs approximately 133 g and measures up to 134 × 38 × 20.5 mm, making it suitable for compact internal layouts in robotic vacuum cleaners.

Stable & Safe: Standardized battery pack design and battery management help effectively control charging and discharging, improving overall operating stability and safety.
